Description
Tandem axle, swivel tow eye, rope rails, auto opening tailgate, spreading chains, Corten 3mm deck, traction 400 floatation wheels, only $22,500 + GST
SPECIFICATION:
BODY TYPE : Flat floor with hinged removable sides
CAPACITY : 8 tonnes by design
CAPACITIES : 4.1m³ level loaded @ 2,000 kgs/m³
BODY LENGTH : 4,000mm (13’2”)
BODY WIDTH : 2,440mm (8’)
BODY DEPTH : 525mm
LOADING HEIGHT : 970mm tandem
RAM TYPE : Via under body hydraulic multi stage ram
TANDEM : 70mm / 6 stud brakeless (9,400kgs @ 40k)
WHEELS : 400 / 60 x 15.5 – 14 ply floatation wheel
CHASSIS : 150 x 100 x 6mm fully welded chassis
TOP CHASSIS : 125 x 75 x 6 RHS
HEADBOARD : Detachable with RHS shock rail & sockets
SIDES : 2-piece detachable hinging sides that bolt in
TAILGATE : Detachable tailgate with RHS top shock rail
TAILGATE LOCKING : Auto lock door with under body door latches
ROPE RAILS : Fitted as standard 1” bore pipe
FLOOR THICKNESS : 3mm corten braced every 400mm
SIDE THICKNESS : Pressed 3mm with up right bracing
DRAW BAR : Rigid chassis A frame drawbar
DRAWBAR SUPPORT : Fitted with 80mm jack support
TOW EYE : Swivel 43mm eye
FINISH : Blasted, zinc base primer, 2 x gloss coats
COLOUR : Standard Blue / silver
TRAILER PRICE : $22,500 + GST + delivery
